Modified plastic

Modified plastic

MANMU carbon fiber products have features of high performance (tensile strength and modulus), good aesthetics and varied technologies. After adjusting the formula (combining with different resin), our carbon fiber compounds will be reinforced with stiffness and resistance properties, which can be widely applied in automotive, aircraft, industrial, sport and leisure.

Item Test standardUnit Classic value
Mechanical propertiesTensile strengthISO 11566MPa3000
Tensile modulusISO11566GPa310
Elongation at breakISO11566%0.95
Electrical propertiesResistivityQJ3074Ω.cm8.23×10-5
OthersBulk densityISO10119g/cm33.2
Linear densityISO11566g/km1630
TowISO11566ends12000
Monofilament diameter μm7.3
Coating thickness μm0.3
Nickel content %50
Cross-sectional area mm2/tow0.55
Twist  None
